Radial Engineering Headlight - 4 Output Guitar Amp Selector
SKU: R800-7096-00
UPC: 676101044245
Be the first to write a review!
Out of Stock - Available to Order
The Headlight is a unity gain guitar amp selector designed to easily integrate onto a pedalboard and provide the ability to switch between as many as four amplifiers with a single footswitch.
The Headlight has a compact footprint that will fit on any pedalboard, but it's still powerful enough to drive up to four amplifiers without sacrificing on tone. The input features a class-A buffer along with Drag Control load correction that allows you to optimize the impedance for your pickups and recreate the feel of plugging your guitar directly into an amp. Custom transformers isolate the outputs to prevent buzz and hum from ground loops, with ground lift switches to further alleviate noise problems. Should you really want to get loud, the mute footswitch can be configured as an 'all on' switch, activating all four amp outputs simultaneously.
Features:
• Four footswitch selectable outputs with LED indicators
• Outputs 2-4 are transformer isolated to eliminate noise
• Class-A input buffer with Drag control for natural tone
• Mute footswitch with dedicated tuner out
Benefits:
• Lets you dedicate amps for clean, rhythm and lead
• Delivers the natural tone of your guitar without artifact
• Small size makes it easy to integrate on pedalboards
• Ensures noise-free connectivity on stage and in studio
Cool Stuff:
• Mute footswitch can also turn on all four amps
• Great for recording multiple amps at once
• Standard 9V power supply (PSU not included)
• Can also be controlled by stage tech
Technical Specification
- Audio circuit type Classic Class-A FET
- Frequency response 30Hz - 30kHz
- Dynamic range 116dBu
- Gain -0.5dBu
- Clip Level +7dB
- Total harmonic distortion 0.01%
- Intermodulation Distortion 0.02%
- Phase Deviation -1.35° @ -20dBu / 1kHz
- Input Impedance 20k to 1MΩ
- Output Impedance 1kΩ
- Noise -112dBu
- Maximum Input +8dB
- Features 180° polarity reverse, Ground lift, Drag Control
- Input Connectors 1/4"
- Output Connectors 1/4"
- Construction 14-Gauge Steel
- Size (L x W x D) 5" x 4.7" x 2"
- Weight 2lb
- Shipping size (L x W x D) 6.5" x 5.1" x 2.5"
- Shipping weight 2.4lb
- Power 9V adaptor / 80mA (Center Pin Negative)
- Conditions For use in dry locations only between 5°C and 40°C
- Warranty Radial 3-year, transferable
