Tannoy VXP 15HP - 1600W 15" PowerDual Active Sound Reinforcement Loudspeaker with Integrated Lab Gruppen IDEEA Class-D Amplification in BlackTannoy VXP 15HP - 1600W 15" PowerDual Active Sound Reinforcement Loudspeaker with Integrated Lab Gruppen IDEEA Class-D Amplification in Black

SKU: 0312-AOS
EAN: 4033653105699

Be the first to write a review!

Available - Item in Stock

Write a review

£1,351.78

£1,126.48 (Ex VAT)

The 1,600-Watt Tannoy VXP 15HP is built around a single 380 mm (15") PowerDual driver mounted within a compact, rugged plywood cabinet, and renowned for its exceptional performance and versatility. The latest high power-handling version of Tannoy’s exclusive point source, VXP 15HP’s constant directivity PowerDual technology and Lab Gruppen IDEEA Class-D amplification ensure high power output with high sensitivity and exceptional efficiency. The point source driver technology allows this unique configuration to deliver exceptionally smooth beam-width characteristics resulting in an even coverage pattern aiding predictable system design. Symmetrical dispersion characteristics enhance speaker placement flexibility, allowing vertical or horizontal mounting of single or multi-cabinet arrays without any compromise in sound quality. The Tannoy VXP 15HP is also ideally suited for use complimenting much larger systems, making it an excellent choice for both installed and portable applications.

• Full range multi-purpose powered sound reinforcement loudspeaker for portable and installation applications
• 1,600 Watt power featuring Lab Gruppen IDEEA electronics Class-D amplification
• 15" PowerDual full range driver for point source phase coherence
• Tightly controlled 75° dispersion for optimum coverage and forward projection
• Ideal for FOH, floor monitor and side fill applications
• Switchable full range or high pass filter operation
• Vented and internally braced plywood enclosure
• Finished with hard wearing semi matt black paint
• Rugged powder coated perforated steel mesh grille
• Blanking plate for optional VTH pole mount
• Versatile mounting via optional custom designed hardware
• Fully balanced input and link output on Neutrik XLR connectors
• Neutrik powerCON for a secure locking mains power connection

Sections

£1,351.78

Technical Specification

  • SYSTEM
  • Frequency response (Full range mode)60 Hz - 25 kHz ±3 dB / 47 Hz - 30 kHz -10 dB
  • Frequency response (Hi-pass mode)100 Hz - 25 kHz ±3 dB / 80 Hz - 30 kHz -10 dB
  • Nominal dispersion75° conical @ -6dB point
  • Directivity factor (Q)9.7
  • Directivity index (DI)9.9
  • Dynamic range106 dB
  • Maximum SPL131 dB peak
  • Crossover typePassive 1.3 kHz
  • Transducers380 mm (1 x 15") constant directivity PowerDual™
  • AMPLIFIER
  • Maximum output power1600 W
  • TypeClass-D
  • ProtectionOutput current limiter, clip limiter, brownout protection and recovery, thermal
  • CONNECTORS
  • Input1 x XLR, balanced
  • Input impedance10 kΩ unbalanced, 20 kΩ balanced
  • Maximum input level for clip+4.5 dBu (hard clip at +14.5 dBu input signal)
  • Link1 x XLR
  • Mains SupplyNeutrik powerCON 20A
  • CONTROLS
  • LevelRecessed potentiometer
  • FilterHi-pass (HPF) / full range (FR), switchable
  • Power modeManual (MAN) / auto (AUTO), switchable
  • POWER SUPPLY
  • TypeSwitch-mode autorange power supply
  • Mains voltage100-240 V~, 50/60 Hz
  • Power consumption150 W @ 1/8 max power
  • PHYSICAL
  • Dimensions (HWD)591 x 451 x 421 mm (23.3 x 17.8 x 16.6")
  • Net weight27.3 kg (60.1 lbs)
