RadialPZ-Deluxe - Compact Acoustic Preamp Pedal

SKU: R800-7320-00
UPC: 676101040384

Be the first to write a review!

Available - Item in Stock


£300.43 (Ex VAT)

This compact, studio-quality instrument preamp pedal has a built-in boost and mute footswitch as well as tone-shaping EQ controls. The PZ-Deluxe features a low-cut filter, a reverse polarity switch and a direct box output for the PA system.

  • Audio circuit typeClass A FET Hybrid Input Stage
  • Number of channels1
  • Frequency response20Hz ~ 18kHz (0/-3dB)
  • Dynamic range105dB
  • Gain+21dB (PZB-Off)
  • Total harmonic distortion0.03% @ -20dB output
  • Intermodulation Distortion0.07%
  • Input ImpedancePZB OFF 6.8K Ohms | PZB On 10M-Ohms
  • Output ImpedanceXLR 600Ω
  • Equivalent Input Noise-108dBu
  • Features180° polarity reverse, Ground lift, HPF, Level Control, EQ Control, Boost
  • Input Connectors1/4"
  • Output Connectors1/4", XLR
  • Size (L x W x D)(6.1" x 3.8" x 2.1") (155 x 96.5 x 53mm)
  • Weight1.75lbs (0.8kg)
  • Power15V 400mA Center Pin Positive Adapter
  • ConditionsFor use in dry locations only between 5°C and 40°C
  • WarrantyRadial 3-year, transferable
