MAXHUBXCore Kit for Microsoft Teams Rooms

Technical Specification

• XC13T MINI-PC
• Product Specification
• TypeMini-PC
• CPUIntel i3-1220P TDP: 28W
• Memory8GB DDR4 3200MHz
• Optional hard disk128GB SATA SSD (M.2-2280 SATA3 up to 6Gb/s)
• GraphicsIntel® UHD Graphics for 12th Gen Intel® Processors
• ChipsetADL PCH-P
• Sound CardUSB Audio, HS-100B, Cmedia
• Network1000Mbps RJ45
• Operating systemWindows 11 IoT Enterprise SAC
• CERTIFICATIONS
• CertificationsMicrosoft Teams Rooms
• I/O PORT
• USB-A 3.04
• LAN1
• USB-C (For Teams Rooms Console)1
• HDMI OUT1
• Audio OUT1
• AC Power1
• Kensington lock slot1
• POWER
• Power Supply ModeAC Power
• Power Requirements100-240V AC 50/60Hz
• Max Power90W
• INCLUDED ACCESSORIES
• Wall Bracket1
• PC Bracket1
• Cable Cover Screw2
• Machine Screw4
• Expansion Screw4
• Self-tapping Screw4
• Cable Cover1
• HDMI Cable (1.8m/5.9ft)1
• Power Cord (1.8m/5.9ft)1
• Quick Start Guide1
• PHYSICAL
• Dimension L × W × H230mm × 185mm × 41.5mm / 9.06" x 7.28" x 1.63"
• Dimension (package) L × W × H342 × 246 × 146mm / 13.46" x 9.69" x 5.75"
• Net Weight1.36kg / 3lbs
• Gross Weight4.36kg / 9.6lbs
• TCP20T TOUCH CONTROL PANEL
• DISPLAY
• Size10.1 inch
• Resolution1920 (H) x 1200 (V)
• Frequency Refresh Rate60Hz
• NTSCMin.62%, Typ.65%
• Back Light UnitELED
• Brightness with glassMin.250cd/m², Typ.300cd/m²
• Life Time≥ 20000 Hours
• TOUCH SYSTEM
• TypeCapacitive touch
• Touch ToolFinger
• Accuracy± 2mm / 0.08"
• Touch Point10 points touch
• Minimum object size6mm / 0.24"
• I/O PORT
• HDMI Ingest (screen share)1
• USB-A (USB Peripheral)1
• USB-C (to PC)1
• 3.5mm (audio out)1
• PHYSICAL
• Dimension L×H×D245 × 164.3 × 77.4mm / 9.65" x 6.47" x 3.05"
• Dimension (package) L×W×H332 × 246 × 166mm / 13.07" x 9.69" x 6.54"
• Net Weight880g / 1.94lbs
• Gross Weight2.38kg / 5.25lbs
• INCLUDED ACCESSORIES
• USB Type-C Cable (Type C-C) 5m / 16.4ft1
• HDMI Cable 1.8m / 5.9ft1
• Quick Start Guide1
• POWER
• Power Requirements15V 3A (Type-C PD)
• Overall Power (Max.)20W
• Standby Power≤ 0.5W
