Radial Engineering J48 - Phantom Powered Premium Active Direct Box
SKU: R800-3001-00
UPC: 676101034079
Be the first to write a review!
Available - Item in Stock
The J48 is a high performance active direct box for live concert touring and professional recording studio applications, with the ability to handle extreme transients without distortion while delivering the natural sound of your instrument.
Most battery-powered guitars and basses will produce as much as 7 Volts when played at maximum volume, which can easily overload typical active direct boxes that are only able to handle about 3 Volts. The J48 uses a unique switching power supply that raises the internal rail voltage so it can handle up to an incredible 9 Volts, resulting in improved signal handling and greater headroom. This additional headroom significantly reduces distortion of all types, allowing the natural tone and character of the instrument to shine through.
• Exceptional headroom and dynamic range
• Retains the natural sound of the instrument
• Merge switch sums stereo instruments to mono
• Powered by 48V phantom, no batteries required
Technical Specification
- SPECIFICATIONS
- Audio circuit type Proprietary analogue circuit with low-noise op-amp
- Frequency response 20Hz ~ 20kHz
- Dynamic range 109dB
- Total harmonic distortion 0.002% @ -5dBu
- Intermodulation distortion 0.003% @ -3dBu
- Phase Deviation +10º at 20Hz | 0º at 1kHz | -1º at 20kHz
- Input Impedance 220kΩ - ¼" input
- Output Impedance 200Ω - XLR output
- Equivalent Input Noise -103dBu
- Noise Floor -99dB below 0dBu
- Maximum Input +10dBu
- FEATURES
- Features Input pad, Mono Sum, 180° polarity reverse, Ground lift, HPF
- Input Connectors 1/4"
- Output Connectors Balanced XLR, 1/4" Thru
- GENERAL
- Construction 14 gauge steel chassis and outer shell
- Size (L x W x D) 3.3" x 5.0" x 2" (84 x 127 x 48mm)
- Weight 1.55 lb (720 g)
- Power 48V phantom - proprietary digital switching
